Second Hand SDLG E6250F Earth Moving Big Excavator 25t 25 Ton 1.2m3 Bucket
The E6250F Excavator is a core product jointly crafted by experts
of SDLG and VOLVO after a full investigation of the Chinese market.
It has the high-strength chassis, reinforced working device and
optimized matching power hydraulic system and suits for a variety
of harsh operating conditions.
1. The turbocharged and intercooled engine is equipped with the
second generation of Deutz electric governor system EMR2, featuring
high power, economy and environment and high reliability, and
enabling better adaptability of the complete machine to operations
in mine; the three-stage filtration intake system improves the
performance and service life of the engine.
2. The hydraulic system is applied with the double-pump constant
power negative flow control and has the "auto-sensing operating
mode" and the "single-pump/double-pump oil supply control mode”,
featuring high efficiency and enabling excellent control
performance of the complete machine.
3. The X-type lower frame is provided with the lengthened crawler
and widened chassis, which enables high stability of the complete
machine; the reinforced working device is supplied as standard, so
that the complete machine is more adapted to harsh operating
conditions.
4. The cab is bright and spacious, features wide vision and good
sealing effect, and is equipped with the high-end shock absorbing
seat, two-stage filtration A/C (cool/heat) and silicone oil rubber
shock absorber with excellent damping effect; all of them offer a
comfortable riding environment.
5. Such working aids as breaking hammer and rotary grab are
optionally available to satisfy the diverse customer needs
Product Paramenters
| Overall width of upper assembly | 2890mm |
| Overall width | 3190mm |
| Overall height | 3040mm |
| Tail swing radius | 2940mm |
| Overall height of engine hood | 2370mm |
| Ground clearance of counterweight | 470mm |
| Wheelbase | 3850mm |
| Crawler length | 4650mm |
| Crawler gauge | 2590mm |
| Crawler pad width | 600mm |
| Min. ground clearance | 470mm |
| Overall length | 10205mm |
| Overall height of boom | 3430mm |
| Overall parameters | |
| Bucket capacity | 1.2m³ |
| Overall operating weight | 24400kg |
| Max. excavation force | 176KN |
| Slew speed | 11.3r/min |
| Traveling speed (low/high) | 3.3/5.5km/h |
| Average ground pressure | 48.5kPa |
| Max. digging radius | 10260mm |
| Max. digging depth | 6980mm |
| Max. digging height | 9690mm |
| Max. dumping height | 6800mm |
| Min. front slewing radius | 3890mm |
| Engine | |
| Model | SD70B |
| Type | Four-stroke,inter-cooled, supercharged |
| Rated Power@Revolution Speed | 138kW |
| Displacement | 7146mL |
| Cylinder bore × stroke | 108*130mm |
| Emission standard | GB20891-2014 China Phase III |
| Rated fuel consumption | 206g/kw.h |
| Max. torque | 870N.m |
| Traveling/swing system | |
| Qty. of carrier rollers (single side) | 2 |
| Qty. of track rollers (single side) | 9 |
| Traveling brake type | Wet disc brake |
| Swing mode | Hydraulic drive internal tooth single-row ball-bearing |
| Swing brake type | Wet disc brake |
| Hydraulic system | |
| Hydraulic control type | Pilot proportional control valve |
| Hydraulic system type | Dual pump constant power negative flow control system |
| Max. flow | 2*240+18L/min |
| Operating pressure | 330kgf/cm2 |
| Fill capacity | |
| Fuel | 380L |
| Engine oil | 32L |
| Hydraulic oil | 330L |
