| Brand Name : | zoomlion |
| Model Number : | Zr160c-3 |
| Certification : | |
| Price : | Negitionable |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability : | 10 |
| Delivery Time : | 30 days after receiving down payment |
Easy transportation. The whole machine can be transported with Kelly bar, which can realize quickly switching between operation and transfer, save 4 hours for assemble and disassemble the equipment .
The well-designed hydraulic system with stable performance can achieve low energy loss, making it more efficient and energy saving.
The imported world-class main pump and main valve in original packaging provide perfect matching and achieve higher work performance and reliability.
2 speeds push/pull crowd cylinder, efficiency increased by 20%.
One button for soil-discharge, one button for hole-cleaning to ease the operations.
Self auto-check , safety and performance monitoring.
The maximum drilling depth gets to 62 meter, broadening application scope of the equipment.
| NAME | SPEC. | |
|---|---|---|
| Torque(KN.M) | 160 | |
| Drilling Diameter(mm) | 1500 | |
| Drilling Depth(m) | inter-locking | 44 |
| Friction | 56/62 | |
| Drilling Speed(r/min) | 5~33 / 5~45 | |
| Engine Model | Cummins 6C 8.3 | |
| Rated Power(kw) | 186 | |
| Rated Engine Speed(r/min) | 2000 | |
| Max.Crowd Force(kN) | 160 | |
| Max.Crowd Cylinder Pull(kN) | 160 | |
| Line Pull(main winch)(kN) | 160 | |
| Line Speed(main winch)(m/min) | 73 | |
| Line Pull(aux.winch)(kN) | 60 | |
| Line Speed(aux.winch)(m/min) | 80 | |
| Operating Mass(t) | 50 | |
| Traction Force(kN) | 330 | |
| Rope diameter(Main winch)(mm) | 26 | |
| Rope diameter(auxiliary winch)(mm) | 18 | |
|
|
