    Xr180d Hydraulic Piling Machine Construction Piling Machine Hydraulic With Parts

    Ask Lasest Price
    Brand Name : Xr180d
    Model Number : Xr180d
    Certification : ISO9001
    Price : Negitionable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 10
    Delivery Time : 30 days after receiving down payment
    • Product Details
    • Company Profile

    Xr180d Hydraulic Piling Machine Construction Piling Machine Hydraulic With Parts

    DescriptionUnitParameter value
    Max. drilling diametermm1800
    Max. drilling depthm60m -standard configuration
    (5-section friction Kelly bar)46
    46m -optional configuration
    (4-section-locking Kelly bar)
    Allowable luffing scope (from center of drill rod to slewing center)mm3560~3900
    Drilling rig dimension in working condition (L*W*H)mm8350*4200*20480
    Drilling rig dimension in transport condition (L*W*H)mm14255*3000*3455
    Weight of overall unit (standard configuration, excluding drilling tool)t58
    EngineModelQSB6.7
    Rated power/speedkW194/(2200r/min)
    Max. working pressure of hydraulic systemMPa35
    Rotary driveMax. torquekN.m180
    Rotational speedr/min7~27
    Crowd cylinderMax. Pushing forcekN160
    Max. Pulling forcekN180
    Max. strokemm5000
    Main winchMax. pulling forcekN180
    Max. single-rope speedm/min65
    Diameter of the steel wire ropemm180
    Auxiliary winchMax. pulling forcekN50
    Max. single-rope speedm/min70
    Diameter of the steel wire ropemm16
    Rotary table slewing angle°360
    TravelingMax. traveling speed of the overall unitkm/h1.5
    Max. climbable gradient of the overall unit%35
    CrawlerWidth of crawler platemm700
    External width of crawler (min.-max.)mm2960~4200
    Center distance between two longitudinal wheels of crawlermm4270
    Average ground pressurekPa94
